DESCRIPTION |
SM400 |
REMARK |
|
Power (Input Source) |
DC Input : 12V (10.6V~15V) |
|
|
Regulated Voltage : DC 10V |
|
Video Signal |
Composite Video Signal 1Vp-p / 75ohm |
|
|
Current Consumption |
Less Than 350mA MAX |
|
|
Sync
Frequency Range |
CCIR |
EIA |
|
|
Horizontal (15.625KHZ) |
Horizontal (15.735KHZ) |
|
Vertical (50HZ) |
Vertical (60HZ) |
|
Resolution |
More Than 450TV Lines |
at Horizontal Center |
|
Non-Linearity |
Vertical : Less Than 15% |
|
|
Horizontal : Less Than 20% |
|
Adjustment |
Gray Scale Should be Classified on External Contrast VR Min |
|
|
Environment
Characteristic |
Atosphere Temperature |
|
|
Operating Temp : 0~50¡É |
|
Storage Temp : -10~60¡É |
|
Humidity : 10%~90% |
|
CRT |
4FNG45 |
SAMVITEC |
|
MTBF |
More Than 30,000HR |
but the CRT Excepted |
|
Accessories |
4P Connector (200mm) |
|
|
6P Connector (200mm) |
|
Weight |
540g |
|
